Audison Forza AF M1.7 bit Mono DSP Amplifier 1200W (7ch DSP)
SKU AF-M1.7-BIT
Price
₹1,49,990.00
The Audison Forza AF M1.7 bit is a mono Class D subwoofer amplifier with a built-in 7-channel DSP, from Audison's Forza range.
- 600 W at 4 ohm, 1000 W at 2 ohm or 1200 W at 1 ohm (RMS, 14.4 V, 1% THD)
- 7-channel DSP at 24-bit / 96 kHz: the amplified subwoofer channel plus 6 pre-outs for further amplifiers
- Inputs: 8 high-level, 8 low-level and optical S/PDIF (up to 192 kHz / 24-bit); up to 12 inputs with the F4IN card, F2O card optional
- USS (Universal Speakers Simulator) for OEM sources and integration with the B-CON hi-res receiver
- Compatible with the DRC MP CAN and DRC AC remote controls
Genuine Audison product.
Quantity
Technical Specs
| Brand | Audison |
| Model | AF M1.7 bit |
| Series | Forza |
| Type | Mono Class D amplifier with 7-channel DSP |
| Output power | 600 W x 1 (4 ohm); 1000 W x 1 (2 ohm); 1200 W x 1 (1 ohm) RMS, 14.4 V, 1% THD |
| DSP | 7 channels (1 amplified + 6 pre-out), 24-bit / 96 kHz |
| Inputs | 8 high-level; 8 low-level; 1 optical S/PDIF (max 192 kHz / 24-bit) |
| Time alignment | 0 – 510 cm (0 – 15 ms) |
| THD | 0.03% |
| Bandwidth | 10 Hz – 600 Hz |
| Signal-to-noise ratio | 105 dBA |
| Damping factor | 140 |
| Efficiency | 84% |
| Power supply / fuse | 11 – 15 VDC / 2 x 35 A |
| Dimensions | 240 x 47 x 156 mm |
| Weight | 1.95 kg |
| MRP (India) | ₹ 1,49,990 |
What's in the Box & Compatibility
- AF M1.7 bit with labelled Forza cable set
About Audison & VA3 Car Studio
Audison is the audiophile car audio brand of Elettromedia S.p.A. — designing high-end amplifiers, DSP processors and speaker systems in Potenza Picena, Italy since 1987. From the bit range that started the in-car DSP revolution to the Forza, Voce, SR and Prima lines, every Audison product is engineered with FEM simulation and rigorous listening tests. VA3 Car Studio supplies genuine Audison products in India, with expert system design, tuning and professional installation support.
